Fractal Design Meshify 2 Compact Black TG Dark Tint Cabinet
Highlights:
- Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
- Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm
- Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases
Only 5 items left!
Don't miss it
Description
Removable front filter
New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access New front nylon filter that can be removed for increased airflow
Robust cooling
Install up to 7 fans, front radiators up to 360 mm, or top radiators up to 240 mm Open interior layout creates a smooth airflow path from intake to exhaust Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 2x 140 mm Dynamic X2 fans included)
Fully featured
Seamlessly integrated steel panel with steel frame support and bolt-free top-latching mechanism Flexible storage options supporting two 2.5”/3.5” drives and up to four SSDs (two SSD brackets included) Improved cable routing with three integrated cable alignment clips and six velcro straps The fully removable top panel opens to provide excellent interior access
| Attribute | Value |
|---|---|
| 3.5"/2.5" Universal drive mounts | 2 (included) |
| Dedicated 2.5" drive mounts | 4 (2 included) |
| Expansion slots | 7 |
| Front interface | 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button |
| Total fan mounts | 7x 120 or 4x 140 mm and 2x 120 mm |
| Front fan | 3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included) |
| Top fan | 2x 120/140 mm |
| Rear fan | 1x 120 mm, (1x Dynamic X2 GP-12 included) |
| Bottom fan | 1x 120 mm (requires removal of HDD cage) |
| Dust filters | Top, front and bottom |
| Fixed velcro straps | Yes |
| Cable routing grommets | Yes |
| Captive thumbscrews | HDD, SSD and PSU brackets |
| Left side panel | Steel |
| Right side panel | Steel |
| Motherboard compatibility | ATX / mATX / Mini-ITX |
| Power supply type | ATX |
| PSU max length | 200 mm (165 mm with HDD cage and front fan) |
| GPU max length | 341 mm (360 mm without front fan) |
| CPU cooler max height | 169 mm |
| Front radiator | Up to 360/280 mm |
| Top radiator | Up to 240 mm |
| Rear radiator | 120 mm |
| Bottom radiator | 120 mm (requires removal of HDD cage) |
| Cable routing space | 17-28 mm |
| Radiator Support – Additional Details | Maximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual. |
| Case dimensions (LxWxH) | 424 x 210 x 475 mm |
| Case dimensions w/o feet/protrusions/screws | 412 x 210 x 455 mm |
| Package dimensions (LxWxH) | 542 x 320 x 554 mm |
| Net weight | Solid: 7.7 kg TG: 8.1 kg |
| Gross weight | Solid: 9.3 kg TG: 9.8 kg |
| Volume | 39.4 Liters |
| Package contents | Meshify 2 Compact Case, User manual, Accessory box |
| Meshify 2 Compact Black TG Dark Tint | SKU: FD-C-MES2C-02, EAN: 7340172702337, UPC: 843276102333, JAN: 4537694276818 |
| Warranty | 2 Years |
